PP2380-AB (USB2380-AB Evaluation Board)





Brief Taiwan 1 Taiwan 2 China
Dimension Taiwan 1 Taiwan 2 China
Schematic Taiwan 1 Taiwan 2 China
Buy It Now


First Impression


The PP2380-AB is PCI Express evaluation board forPLX USB2380-AB, aPCI Express Gen 1 to USB 2.0 Hi-Speed Peripheral Controller. It features one PCI Express Gen 1 x1 port and one USB 2.0Hi-Speed client port. The PP2380-AB provides a matching bandwidth at 480Mbps between the PCI Express Gen 1 bus and the USB 2.0Hi-Speed bus. The controller can easily add a USB 2.0 client port to an existing system such aslaptop PC with PCIe slot, as well as convert an existing PCI Express function (endpoint) to a USB 2.0 product. The PP2380-AB can configure the PCIe Gen1 as one x1 upstream port or one x1 downstream port. The flexibility allows different system configurations to achieve the maximum performance of the product.



    Specification


    USB 2.0 Client Interface

  • USB 2.0 Specification Compliant
  • 1 upstream port
  • Supports Hi-Speed, Full-Speed modes
  • Four Descriptor-based DMA channels for automatic data transfers
  • Supports USB Duet® Technology
  • Support for Bulk, Isochronous, and Interrupt Endpoints
  • USB 2.0 link power management states: L0, L1, L2
  • Micro B Receptacle connector

    Specification


    PCI Express Interface

  • PCI Express Gen 1 (2.5Gbps)
  • Electrical Compliance to PCI Express Base Specification r2.0
  • one x1 upstream port
  • PCI Express Power Management
    All link power management states: L0, L0s, L1, L2/L3 Ready, and L3
    Device states: D0 and D3(hot & cold)
    Vaux, Wake#, Beacon support
  • 256 byte maximum payload size
    Note:
    We can not provide driver software and technical support, to get RDK and technical support services,

    Please contact PLX product sales representative or distributor.
    http://www.avagotech.com/company/contact/



Applications

Target applications for the PP2380-AB adapter as a PCI Express endpoint include PCs, servers, docking stations, printers, and PCI Express embedded systems.
Add a USB 2.0 Client Port to PCI-E Based Systems

The PP2380-AB can be used to easily add a USB 2.0 client port to any PCI Express based embedded system.
Add a USB 2.0 Client Port to ExpressCard-Based Systems
The PP2380-AB can be used to easily add a USB 2.0 client port to any PCI Express based embedded system.


Package Content


Note:
We can not provide driver software and technical support, to get RDK and technical support services,

Please contact PLX product sales representative or distributor.
http://www.avagotech.com/company/contact/

PP2380-AB
Unit price: USD 178.
PP2380-AB
(USB2380-AB Evaluation Board) x1
Y05-U21-100
(USB A-B 100cm cable) x1



PE3A V3.2
Unit price: USD 125.
PE3A
(PCI-Express or USB 3.0 to ExpressCard Adapter ) x1
SPB087
(ExpressCard 34 to 54 Bracket) x1
Y04-V01-015
(External 5V/12V power supply) x1
