USB3380EVB  (USB3380 Evaluation Board)


Introduction:
The USB 3380 is a PCI Express Gen 2 to USB 3.0 SuperSpeed Peripheral Controller. It features one PCI Express Gen 2 x1 port and one USB 3.0 SuperSpeed client port. The USB 3380 provides a matching bandwidth at 5 GT/s between the PCI Express Gen 2 bus and the USB 3.0 SuperSpeed bus. The controller can easily add a USB 3.0 client port to an existing PCI Express system, as well as convert an existing PCI Express function (endpoint) to a USB 3.0 product. The USB 3380 can configure the PCI Express port as one x1 upstream port or one x1 downstream port. The flexibility allows different system configurations to achieve the maximum performance of the product.

    Specification

    USB 3.0 Client Interface

  • USB 3.0 Specification.
  • 1 upstream port.
  • Supports SuperSpeed, Hi-Speed, Full-Speed modes.
  • Four Descriptor-based DMA channels for automatic data transfers.
  • Supports USB Duet® Technology.
  • USB Auto-Enumeration Technology
  • Support for Bulk, Isochronous, and Interrupt Endpoints.
  • USB Power Management USB 3.0 link power management states: U0, U1, U2, U3
  • USB 2.0 link power management states: L0, L1, L2

    PCI Express Interface

  • PCI Express Gen 2 (5Gbps)
  • Electrical Compliance to PCI Express Base Specification r2.0
  • PCIe interface and integrated root complex provides two configurations:
    one x1 upstream port
    one x1 downstream port
  • PCI Express Power Management All link power management states: L0, L0s, L1, L2/L3 Ready, and L3
    Device states: D0 and D3(hot & cold)
    Vaux, Wake#, Beacon support
  • 256 byte maximum payload size
  • ExpressCard 2.0 compliance


Note:
We can not provide driver software and technical support, to get RDK and technical support services,

Please contact PLX product sales representative or distributor.
http://www.avagotech.com/company/contact/


Applications:

Target applications for the USB3380EVB adapter as a PCI Express endpoint include PCs, servers, docking stations, printers, and PCI Express embedded systems.
Add a USB 3.0 Client Port to PCI Express-Based Systems
The USB 3380 can be used to easily add a USB 3.0 client port to any PCI Express based embedded system.
As a PCI Express endpoint, the USB 3380’s Standard PCI Express interface connects directly to any PCI Express bus.

Add a USB 3.0 Client Port to ExpressCard-Based Systems
The USB 3380 can be used to easily add a USB 3.0 client port to any ExpressCard based embedded system.


Add a USB 3.0 Client Port to PCI Express-Based Systems
The USB 3380 can be used to easily add a USB 3.0 client port to any PCI Express based embedded system.
As a PCI Express endpoint, the USB 3380’s Standard PCI Express interface connects directly to any PCI Express bus.

OPTION



Buy It Now

Note:
We can not provide driver software and technical support, to get RDK and technical support services,

Please contact PLX product sales representative or distributor.
http://www.avagotech.com/company/contact/
  • USB3380-AB EVK-RC
  • USB3380-EVB
USB3380-AB EVK-RC
Unit price: USD 452.

    USB3380-AB EVK-RC

  • USB3380EVB-R
    (mini PCI Express to usb 3.0 Adapter) x1
  • USB3380RCB x1
  • Screw x2
Y09-U11-100
(USB 3.0 Type A to USB Micro B Cable 100cm) x1
AC-SPP34
(AC/DC 100V~240V to DC 12V/2A 5V/2A power adapter) x1
Y04-V01-015
(External 5V/12V power supply) x1



USB3380EVB
Unit price: USD 195.
USB3380EVB
(mini PCI Express to USB 3.0 Adapter) x1
Screw x2




OPTION

  • ADP
  • PE3B
  • PP2U
ADP
Unit price: USD 62.
ADP (Mini PCI-E / PCI-E adapter) x1
Screw x2
JP0875 ( Standard Height PCI express bracket ) x1
PE3B
Unit price: USD 162.
PE3B
( Mini Card to ExpressCard Adapter ) x1
Y05-U17-060
(USB A Male to DC Power Cable) x1
SPB087
(ExpressCard 34 to 54 Bracket) x1
Screw x2
PP2U-E V1.0
Unit price: USD 62.
PP2U
( USB3.0 Host to PCIe Adapter) x1
JP0830B
(Standard Height PCI express bracket) x1




Documents Download
Brief  Taiwan 1   Taiwan 2 Mirror   China Mirror
USB3380EVB
Schematic
 Taiwan 1   Taiwan 2 Mirror   China Mirror
USB3380-AB EVK-RC
Schematic
 Taiwan 1   Taiwan 2 Mirror   China Mirror
