MR11-EC2C-6250
PP1U (USB3.0 Host to PCIe Adapter)
Introduction:
USB 3.0--is also considered SuperSpeed USB--high-frequency devices for those with PC or audio/connect various devices provide a standard interface. From the keyboard to high throughput disk drives, various devices are able to use this low-cost interface for Plug and play connection running smoothly, users without spending too much effort on it. New USB 3 while maintaining compatibility with USB 2, also provides several enhanced features below:
- greatly improved up to 5Gbps bandwidth--full-duplex.
- Achieving a better power management.
- Can host more power for the device, enabling USB-rechargeable batteries, LED lighting and Mini fan application.
- Allows host identification devices faster.
- The new agreement makes the processing more efficient.
In order to better achieve USB3.0 interfaces development and utilization of Bplus tech PP1U both USB3.0 expansion card, this expansion card is a land of 1 (PP1U) or 2 (PP2U) ultra high speed USB3.0 interfaces, PCI Express card, which complies with the PCI Express2.0 system specification, Connection to USB3.0 peripherals Shi can to highest up 5Gbps of rate transmission file, while keep and existing of USB peripherals products of compatibility, compatible USB2.0,1.1,1.0, USB full series peripherals, support USB hot plug dial and is plug play function, support any USB device including u disk, and USB external hard drive, and MP3, and external optical drive, and digital camera, and camera and so on, and in using Shang with ancestors USB products as, no any of difference.
 |
- Complies with PCI-Express version 2 version 1
- USB3.0 SuperSpeed specification complies with the xHCI specification version 1
- main control chip: Renesas uPD720202 chipset
- maximum transfer rate of up to 5Gbps, up from USB2.0 480Mb/s, up to 10 times
- Backward compatible with USB2.0 and USB1.1, USB1.0
- transfer rate: 5G/480M/12M/1.5Mbps
- USB power supply output: up to 5V
- USB-IF battery charging specification version 1.2
- built-in 4P power interface
- support USB hot-plug function WQHL certification Microsoft
- supported Windows 2000/XP/2003/Vista/win7 32/64
Features
 Software download (ver 3.0.16.0) March 29, 2012 |
 Firmware download (ver 2.0.1.1) March 12, 2012 |
| xHCI Driver for Linux Kernel v2.6.28 (Sample source) Mar.,2012 |
|
 Tool for DOS |
|
| Software download (ver 3.0.12.0) |
|
| Software download (ver 3.0.8.0) |
|
| Firmware download (ver 2.0.1.0) February 1st, 2012 |
|
| xHCI Driver for Linux Kernel v2.6.20 (Sample source) Mar.,2012 |
|
| Firmware download (ver 2.0.0.6) October 24th, 2011 |
|
| Serial ROM Write Tool for Windows (Ver.2.0.0.0, 2012/02/16) [ Release Note ] |
|
| Serial ROM Write Tool for DOS (Ver.2.0.0.0, 2012/02/16) [ Release Note ] |
|
| Serial ROM Write Tool for Linux (Package Version.20120216, 2012/02/16) [ Release Note ] [ License ] |
|
| PP1U Package Contents | |
| Unit price: US$ 25 | |
PP1U ( USB3.0 Host to PCIe Adapter) x1 |
JP0875 (Standard Height PCI express bracket) x1 |
| Documents Download | |||
| Brief | Taiwan 1 |
Taiwan 2 Mirror |
China Mirror |
| Software download ver 3.0.16.0 Mar 29,2012 |
Taiwan |
Taiwan 2 Mirror |
China Mirror |
| xHCI Driver for Linux Kernel v2.6.28 (Sample source) Mar.,2012 |
Taiwan |
Taiwan 2 Mirror |
China Mirror |
| Firmware download ver 2.0.1.1 March 12, 2012 |
Taiwan |
Taiwan 2 Mirror |
China Mirror |
| xHCI Driver for Linux Kernel v2.6.20 (Sample source) Mar.,2012 |
Taiwan |
Taiwan 2 Mirror |
China Mirror |
| Tools for DOS | Taiwan |
Taiwan 2 Mirror |
China Mirror |
| Software download ver 3.0.12.0 |
Taiwan |
Taiwan 2 Mirror |
China Mirror |
| Software download ver 3.0.8.0 |
Taiwan |
Taiwan 2 Mirror |
China Mirror |
| Firmware download ver 2.0.1.0 February 1st, 2012 |
Taiwan |
Taiwan 2 Mirror |
China Mirror |
| Firmware download ver 2.0.0.6 October 24th, 2011 |
Taiwan |
Taiwan 2 Mirror |
China Mirror |
| Serial ROM Write Tool for Windows (Ver.2.0.0.0, 2012/02/16) |
Taiwan |
Taiwan 2 Mirror |
China Mirror |
| Serial ROM Write Tool for DOS (Ver.2.0.0.0, 2012/02/16) |
Taiwan |
Taiwan 2 Mirror |
China Mirror |
| Serial ROM Write Tool for Linux (Package Version.20120216, 2012/02/16) |
Taiwan |
Taiwan 2 Mirror |
China Mirror |
| Dimension (PDF): | Taiwan 1 |
Taiwan 2 Mirror |
China Mirror |
| Schematic (PDF): | Taiwan 1 |
Taiwan 2 Mirror |
China Mirror |
