   M2P4B
PCIe 3.0 X4 to M.2 PCIe Gen3 SSD Adapter







Brief Taiwan 1 Taiwan 2 China
Dimension Taiwan 1 Taiwan 2 China
Schematic Taiwan 1 Taiwan 2 China
3D Model Taiwan 1 Taiwan 2 China
Compatibility List Taiwan 1 Taiwan 2 China
SSD Adapter Selection Guide Taiwan 1 Taiwan 2 China
Web-shop


First Impression


M2P4B adapter enables PCIe base M.2(NGFF) PCIe SSD as a HDD Card for desktop PC.

M2P4B design for M.2(NGFF) PCIe Gen3 SSD.

    Function


  • Allows user to use standard PCIE base M.2 SSD to PCIe x4 in the Desktop or Laptop.
  • Transparent to the operating system and doesnot require any software drivers.

    Specifications


  • M.2 SSD to PCIe X4 adapter.
  • M.2 Specification Revision 1.0
  • Support 2230/2242/2260/2280type M.2 Card dimension.
  • Support M.2 Socket 3 PCI-e-based SSD Module.
  • Support M.2 Key M Card Type.
  • Support PCIe Gen3 x4

    Boot from M.2 SSD storage.


We successfully installed the system through M2P4B Samsung SSD, and the success of the boot.
Operating platform follows:
CPU: Intel® Pentium® Processor G3258
MB: ASROCK Z97 Killer
OS: Windows 8.1 64bit
Adapter : M2P4B
SSD Hard Drive: Samsung XP941-128G M.2(NGFF) PCIe x4 SSD

Most Z97 chipset can support boot with PCIe’s storage.
You can simply install the OS but chose the M.2 storage.
The chose setup BIOS to boot from it.


    Note:
    Because z97’s BIOS is UEFI BIOS, make sure you boot from “UEFI: your storage name”.
  • If you use generic’s USB dongle to install your OS, then you need to choose “UEFI: generic storage”.
  • If you use CD ROM to install your OS, please choose “UEFI: WDC WD10EARS-OOMVMBO”

    Boot selection:





M.2 SSD to PCI-E from factor Adapter Compatibility List

2013Dec13
Gerry Chen
Brand / Model Function Interface Size M2P4A M2P4S M2PS M2P4B Note
Samsung SM951 512GB SSD PCIe key M 2280 Pass Pass NG Pass
Samsung SM951 256GB SSD PCIe key M 2280 Pass Pass NG Pass
Samsung SM951 128GB SSD PCIe key M 2280 Pass Pass NG Pass
Samsung XP941
MZHPU128HCGM-00000
SSD PCIe key M 2280 Pass Pass NG Pass
Samsung XP941
MZHPU256HCGL-00000
SSD PCIe key M 2280 Pass Pass NG Pass
Samsung XP941
MZHPU512HCGL-00000
SSD PCIe key M 2280 Pass Pass NG Pass
Samsung M.2 128G
MZ-NPD1280
SSD SATA key B / M 2280 NG NG Pass NG
Samsung M.2 128G
MZNTD128HAGM
SSD SATA key B / M 2280 NG NG Pass NG
BPLUS M2EM SSD SATA key B / M 2242 NG NG Pass NG
ADATA AXNS341N-64GM-B SSD SATA key B / M 2242 NG NG Pass NG
Sandisk X110 SSD SATA key B / M 2242 NG NG Pass NG
Samsung MZNTD128HAGM SSD SATA key B / M 2280 NG NG Pass NG
Intel
SSD Pro 1500 Series
SSD SATA key B / M 2280
2242
NG NG Pass NG
Intel
SSD 530 Series
SSD SATA key B / M 2280 NG NG Pass NG
Tohsiba THNSNHGDNT SSD SATA key B / M 2280 NG NG Pass NG
LITE-ON L8T-128L6G-HP SSD SATA key B / M 2280 NG NG Pass NG

Brand Function Interface Size M2P4A M2P4S M2PS M2P4B Note
Key M Key M Key B Key M
M2P4A / M2P4B / M2P4S (M.2 Key M)
Designed for PCIE x4 based M.2 (NGFF) SSD module

M2PS (M.2 Key B)
Designed for SATA based M.2 (NGFF) SSD module



    Web-shop



M2P4B
Unit price: USD 50.

M2P4B
(PCIe 3.0 X4 to M.2 PCIe Gen3 SSD Adapter) x1
Y02-D01-060
(Dupont 2PIN Cable) x1
Screw x2




Buy Related Items


PCIe SSD module
M2P4S
M2P4A
