  M2BU3S
M.2 key B USB 3.0 module to mini card Rev 2.1 Adapter






Brief Taiwan 1 Taiwan 2 China
Buy It Now


First Impression


The M2BU3S adapter is designed for desktop/Laptop PCs that convert 5G/4G/3G wireless M.2 key B USB 3.0 module to full/half mini card Rev 2.1 slot.
 You can insert your M.2 card (Socket 2 SSIC-base WWAN) such as GSM, HSPA(3.5G), GPS, LTE,4G,5G cards to this adapter .



    Function


  • Allows user to use M.2 Socket SSIC-based WWAN Module to mPCIe Slot in the Desktop or Laptop.
  • Supports USB 3.0 interface of M.2 Cards (Socket 2 SSIC-base WWAN) such as CDMA, WLAN,WWLAN, HSPA MODEM , GPS, 4G, 5G, LTE, Mini Card to desktop PC.
  • Support Full size and half size mPCIe slot

    Specifications


  • USB 3.0 M.2 B key Card to mini card Rev 2.1 adapter.
  • M.2 Specification Revision 1.0
  • Universal Serial Bus Specification Revision 3.0
  • Support 2230/2242 M.2 Card dimension.
  • Support M.2 Socket SSIC-based WWAN Module.
  • Support M.2 Key B Card Type.

    System Requirement


  • Mini PCI-E slot support mini card Specification Revision 2.1



M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name UN32B M2BU3S-U3D M2BU3S-U2D M2BU3S-PU M2MU2
Function M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mPCIe
Interface PCIe & USB 3.0 USB 3.0 USB 2.0 PCIe 2x or SATA USB 2.0
M.2 SPEC Socket 2 PCIe & USB3.0 dual bus WWAN Socket 2 SSIC-based WWAN Socket 2 SSIC-based WWAN Socket 2 Socket 2 SSIC-based WWAN
Application 5G / 4G / 3G / CDMA / LTE / GPS module 5G / 4G / CDMA / LTE / GPS module 5G / 4G / CDMA / LTE / GPS module PCIe 2x or SATA SSD module 5G / 4G / CDMA / LTE / GPS module
Module KEY B B B B B
Support Card Type 3030/3042/3050/3052 2242,50,52 / 3042,50,52 2242,50,52 / 3042,50,52 2242,50,52 / 3042,50,52 2230/2242/3030/3042

M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name MN25A M2MP1-A M2MP1-E M2MP3-A M2MP3-E
Function M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe
Interface PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0
M.2 SPEC Socket 1
First PCIe Lane
Socket 1
First PCIe Lane
Socket 1
First PCIe Lane
Socket 1
Second PCIe Lane
Socket 1
Second PCIe Lane
Application WiFi+BT module WiFi+BT module WiFi+BT module WiFi+BT module WiFi+BT module
Module KEY E A E A E
Support Card Type 2230 2230/2242/3030/3042 2230/2242/3030/3042 2230/2242/3030/3042 2230/2242/3030/3042

mini PCI-E to M.2 (NGFF) Adapter comparison
Model Name NM51A NM61A-P01 NM61A-U3
Function mPCIe to M.2 mPCIe to M.2 mPCIe to M.2
Interface PCIe & USB2.0 PCIe USB3.0
M.2 SPEC Socket 1
First PCIe Lane
Socket 2
First PCIe Lane
Socket 2
USB3.0

Application WiFi+BT module PCIe Interface module USB Interface module
Module KEY A E B M B M
Support Card Type 3042/3050/3052/3060 3042、50、52、60、80 3042、50、52、60、80



Package Content




M2BU3S-U3D
Unit price: USD 50.

M2BU3S-U3D
M.2 key B USB 3.0 module to mini card Rev 2.1 Adapter x1
with Dual SIM Card slot
Screw x4
Flat-Head Screw x2

Washer x2



M2BU3S-U2D
Unit price: USD 47.

M2BU3S-U2D
M.2 key B USB 2.0 module to mini card Rev 2.1 Adapter x1
with Dual SIM Card slot
Screw x4
Flat-Head Screw x2

Washer x2



M2BU3S-PU
Unit price: USD 47.

M2BU3S-PU
M.2 PCIe x2 module to mini card Rev 2.1 Adapter x1
Screw x4
Flat-Head Screw x2

Washer x2
