   U3EX
(USB 2.0 / 3.0 Test Fixture )


Introduction:
The USB Fixture is a test tool for USB 2.0 / 3.0 interface with multi-functions of voltage swtich, voltage test and current test.
It's especially designed to save valuable labor and time in the production environment. The USB Fixture is constructed of high quality components for years of trouble free service.



        Function


  • Test connector for all of signal and power pins
  • LED indicates power status
  • Over-current protection with power switch IC
  • Alternative Output Voltage: 5v to 5v/3.3v
  • Voltage can be tested conveniently and directly
  • Current can be tested conveniently and directly
  • External power supply support

Dimension : Width: 65mm Length:18mm PCB Thickness :1.6mm


Different switch and jumper can perform different function.





U3EX Package Contents
Unit price: US$ 50
U3EX (USB 2.0 / 3.0 Test Fixture )


Documents Download
Brief (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
Dimension: (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
Schematic (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
User manual(PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
