    P32S-P32F

M.2 (NGFF) to USB3.0 Extender Board





Brief Taiwan 1 Taiwan 2 China
Selection Guide   Tawan   Taiwan 2 Mirror   China Mirror
Buy It Now


First Impression


M.2 stands for Next Generation Form Factor which is invented for PCI-SIG by Intel and it is developed for flat and high-efficiency equipment such as Ultrabook™ or Tablet PCs. It is a natural transition from the Mini Card and Half Mini Card to a smaller form factor in both size and volume which supports multiple function add-in cards/modules including: Wi-Fi, Bluetooth, global navigation satellite systems, near field communication, Hybrid digital radio, wireless gigabit alliance (WiGig), wireless wide area network and solid-state storage devices. Also adds functionality to USB 3.0, display Port, SDIO and SSD-PCIe


  Function


  • Allows use USB 3.0 device to type 2242 Key B M.2 type slot in the Desktop or Laptop.
  • Design the FFC (Flat Flexible Cable) cable for flexible use.

  Specification


  • M.2 Specification Revision 0.9
  • Universal Serial Bus Specification Revision 2.0
  • Support type 2230 M.2 Card dimension.
  • Support M.2 Key B Card Type.
  • SATA external power: Standard 15 PIN (5V requirement)

Notice:
Only support USB 3.0 base type2242 Key B M.2 slot, PCIe and SATA base can't support.



Package Content


P32S-P32F
(U32S-U32F)
Unit price: USD 100.

P32S x1
P32F x1
with
Y02-D01-060 (Dupont 2PIN Cable) x1
FFC0510P-020A (FFC cable 20cm) x1

Flat-Head Screw x1
