    PN15A
M.2 A E Key Wireless Card to PCIe Adapter






Brief Taiwan 1 Taiwan 2
Web-shop


First Impression


The PN15A PCI-E M.2 A E Key Card passive adapter is designed for wireless application on desktop PCs that convert half-size MiniCard to USB 5pin Header or standard PCI-Express 1x slot.
You can insert your USB type M.2 card to this adapter then plug to USB 5pin header port through USB cable.
Or insert your PCI-E type M.2 card into this adapter then insert to PCI-E 1x connector.

Also, WiFi & Bluetooth Combo card such as Intel® Wi-Fi 6E AX210NGW can be used for supporting both Wireless by PCIe and Bluetooth by USB at the same time.

    Specification


  • PCI Express M.2 A E key Card to PCI Express adapter.
  • Supports system bus interface: PCIe & USB2.0 .
  • Support PCIe M.2 Card :IEEE WLAN802.11a/b/g/n, 802.11d, 802.11e, 802.11i, 802.11h, 802.11ac, 802.11ax
  • Standard Height PCI Express Add-in Card – max 4 ANTs for Standard Height.
  • U.FL/IPX to SMA / RP-SMA pigtail WiFi RF cable adapter
    4G / 5G antenna: SMA connector ,
    Wireless antenna : RP-SMA connector
  • PN15A: Transparent to operating systems and does not require any software drivers

    Notice


  • No driver CD accompanied
  • Make sure you download and install the proper driver before you install the adapter







  Web-shop




PN15A
Unit price: USD 50.

PN15A
M.2 A E key Wireless Card to PCIe Adapter x1
with RF22008B x2
RF22008B
(MHF4 to RPSMA cable 8cm)
Y05-U02-060
(USB Dupont 5PIN Cable) x1
Flat-Head Screw x2
