 PE4H (PCIe passive adapter ver2.4)



Introduction:

The PE4H is designed for Notebook PCs that converts PCI Express 16X Add-on Card to ExCard or mPCIe or PCIe 1x connecter.

This adapter allows you to use your existing PCI-E 16X Card in the notebook PC for test.

PE4H ver 2.4



OPTION



OPTION: DIY BOX v1.0 only support PE4H V2.4a / PE4L V2.1
*Installation Guide
 internal dimension: 32 x 20 x 23 cm(DxWxH)
External dimension: 34 x 22 x 31 cm



    Features

  • PE4H-EC2C allows user to test PCI Express Add-in-Card on the ExpressCard slot.
  • PE4H-PM3N allows user to test PCI Express Add-in-Card on the PCI Express mini card slot.
  • PE4H-HP1A allows user to extend PCIe 1x add-on card to test.
  • Cable Length:
    Type A
    PE4H-EC060A / PE4H-PM060A / PE4H-HP060A Length 60cm
    Other OEM demands as listed below, please contact our China Office.
    PE4H-EC030A / PE4H-PM030A / PE4H-HP030A Length 30cm OEM
    PE4H-EC100A / PE4H-PM100A / PE4H-HP100A Length 100cm OEM
    PE4H-EC150A / PE4H-PM150A / PE4H-HP150A Length 150cm OEM
    PE4H-EC200A / PE4H-PM200A / PE4H-HP200A Length 200cm OEM
    PE4H-EC300A / PE4H-PM300A / PE4H-HP300A Length 300cm OEM
    PE4H-EC400A / PE4H-PM400A / PE4H-HP400A Length 400cm OEM
    PE4H-EC500A / PE4H-PM500A / PE4H-HP500A Length 500cm OEM


    System Requirements

  • Running Windows 7, XP (Not compatible with Apple Computers)
  • Linux
  • ExpressCard slot on notebook
  • Power Supply (ATX or DC power units)
  • PCIe Video Card (PCIe 1.0, 2.0, or 2.1)


    Notice:

  1. PE4H is PCIe 1x bandwidth limit passive adapter in compliance with Expresscard and mPCIe specification.
  2. PE4H design for engineering test. NOT for home or office use.
  3. Basically, PCIe add-on card designed for desktop. We can’t guarantee it compatibility with your laptop. Depends on OS version, notebook’s BIOS, device driver,
  4. Almost PCIe 16x video card can’t get enough memory resource are allocated. Can’t work in your laptop.
  5. For more graphics cards experiences. Please visit web-site here.


PE4H ver2.4 12V/5V/3.3V power current limit
  DC15~20V input Floppy 12V/5V input ExCard 3.3V input
PCIe 12V 12V/3A (Max) 12V/6A (Max) 12V/0A
USB 5V 5V/1.5A (Max) 5V/1.5A (Max) 5V/1A (Max)
PCIe 3.3V 3.3V/3A (Max) 3.3V/3A (Max) 3.3V/1.3A (Max)


PE3, PE4L, PE4H PCIe passive adapter comparison                    2010/Oct/30
Functions comparison
PE3
ver1.0
PE3A
ver1.0
PE4L
ver1.4
PE4L
ver1.5
PE4H
ver2.0a
PE4H
ver2.4
USB interface
USB2.0
USB3.0
USB2.0
USB2.0
USB2.0
USB2.0
PCIe interface
1x
1x
1x,2x,4x,8x,16x
1x,2x,4x,8x,16x
1x,2x,4x,8x,16x
1x,2x,4x,8x,16x
3.3V power switch protect your host
No
No
Yes
Yes
Yes
Yes
12V power fuse Trip current (Itrip)
Not support
Not support
Not support
Not support
10A
10A
Custom PCIe external cable support
NO cable
NO cable
30cm, 100cm
30cm, 100cm
30cm, 100cm
30cm, 100cm
Power LED
No
No
3V LED
3V LED
3V LED
PERST#,12V,5V,3V
5V USB power from expresscard
Internal 500mA
Internal 1000mA
PSU (floppy conn)
PSU(floppy conn)
DC Jack or PSU
DC Jack or PSU
12V power from external DC jack
No
No
DC12V
DC12V
DC15~20V
DC15~20V
12V power from PSU (floppy power)
No
No
Yes
Yes
Yes
Yes
DC 19V to 12V
No
No
No
No
12V/2A
12V/3A
12V to 5V
No
No
No
No
5V/3A
5V/1.5A
5V to 3.3V
No
No
3.3V/3A
3.3V/3A
3.3V/3A
3.3V/3A
PERST# delay switch
No
No
No
7sec
No
0 or 7 or 15 sec
PCBA Dimension
108.5x34mm
108.5x34mm
64.3x46.7mm
64.05x46.55mm
185.25x36mm
185.25x36mm


  • PE4H-EC2C
  • PE4H-PM3N
  • PE4H-HP1A
PE4H-EC2C ver2.4 Package Contents
Unit price: US$ 91
PE4H
(PCIe passive adapter Ver2.4) x1
EC2C
( Express card to the converted port adapter) x1
Y19-H02-060
(PCIe Male to Male cable 60cm) x1
Y04-V01-015
(External 5V/12V power supply) x1
SWEX
(ATX Power Supply Power-On Switch)





  • EC2C
  • PM3N
  • HP1A
  • DIY BOX

EC2C option

Unit price: US$ 20
EC2C
(Express card to the converted port adapter)



SPB087 option

Unit price: US$ 2
SPB087
(ExpressCard 34 to 54 Bracket)
Notice:
SPB087 (Expersscard 34 to 54 bracket) is design for BPLUS own product. It may cannot install properly to other expresscard brand.




  • Y19-H02-030
    PCIEMM-030A
  • Y19-H02-060
    PCIEMM-060A
  • Y19-H02-100~500
    PCIEMM-100A~500A
  • SWEX

Y19-H02-030
Unit price: US$ 8
Y19-H02-030
(Custom PCIe Male to Male cable 30cm) x1


Item / 項 目
PE4L
ver1.5
PE4L
ver2.1
PE4H
ver2.4
PE4H
ver3.2
USB interface
USB介面
USB インターフェース
USB2.0
USB2.0
USB2.0
USB2.0
PCIe interface
PCIe介面
PCI Expressインターフェース
1x,2x,4x,8x,16x
1x,2x,4x,8x,16x
1x,2x,4x,8x,16x
16x
PCIe Spec/Speed
PCIe規格/速度
PCIe規格・速度
Gen1/2.5Gbps
Gen2/5Gbps
Gen1/2.5Gbps
Gen2/5Gbps
3.3V power switch protect your host
3.3V的電源開關,保護你的主機
3.3V電源保護(ホストへの逆流防止)
Yes

有り
Yes

有り
Yes

有り
Yes

有り
12V power fuse Trip current (Itrip)
12V電源保險絲跳閘電流
12V 電源切断電流値(Itrip)
No
不支持
非対応
10A
10A
10A
Custom PCIe external cable support
自定義外部的PCIe電纜支援
専用PCIe外部電源ケーブル(最大値)
30cm, 100cm
60cm
30cm, 100cm
60cm
Power LED
電源LED
3V LED
3.3V電源LED
3V LED
3.3V電源LED
PERST#,12V,5V,3V
PERST#用LED
電源LED
(12V,5V,3.3V)
PERST# ,3V
PERST#用LED
電源LED
(3.3V)
5V USB power from expresscard
來自ExpressCard 的5V USB電源
USBバスパワー (5V)
DC Jack or PSU
DC插口或軟碟電源連接器
DCジャックor
フロッピー
電源コネクタ
DC Jack or PSU
DC插口或軟碟電源連接器
DCジャックor
フロッピー
電源コネクタ
DC Jack or PSU
DC插口或軟碟電源連接器
DCジャックor
フロッピー
電源コネクタ
DC Jack or ATX 24pin connector
DC插口或ATX連接器
DCジャックor
ATX 電源コネクタ
12V power from external DC jack
外部直流12V電源輸入插孔
DCジャック外部電源入力
(内部12V電源)
DC12V
DC12V
DC15~20V
DC15~20V
12V power from PSU (floppy power)
軟碟12V電源連接器輸入功率
ロッピー電源コネクタによる12V
電源入力
Yes

有り
Yes

有り
Yes

有り
No
不支持
非対応
DC 19V to 12V
直流19V至12V
19V入力-12V変換
No
不支持
非対応
No
不支持
非対応
12V/3A
19V/3A
12V to 5V
12V輸入5V的轉換
12V入力5V変換
No
不支持
非対応
No
不支持
非対応
5V/1.5A
5V/1.5A
5V to 3.3V
5V輸入3.3V的轉換
5V入力-3.3V変換
3.3V/3A
3.3V/3A
3.3V/3A
3.3V/3A
PERST# delay switch
延時開關
PERST# 遅延変換スイッチ
0秒, 7秒
0秒, 0.5秒, 7秒
0秒, 7秒, 15秒
0秒, 9.8秒, 15秒
PCBA Dimension
外型尺寸
本体外形寸法
64.05x46.55mm
64.05x46.55mm
185.25x36mm
139.60x150.00mm


Documents Download
PE4H ver2.4 Brief (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
PE4H ver2.4 Schematic (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
PE4H ver2.4 dimension (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
PE4H ver2.0a Brief (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
PE4H ver2.0 a Schematic (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
PE4H ver2.0a dimension (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
PE4H ver1.0 Brief (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
PE4H ver1.0 Schematic (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
EC2C ver1.0 dimension (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
EC2C Schematic (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
PM3N dimension (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
PM3N ver 1.00 Schematic (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
PM3N ver 1.10 Schematic (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
PM3N ver 1.2 Schematic (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
HP1A dimension (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
HP1A Schematic (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
SWEX Brief (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
SWEX dimension (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
SWEX Schematic (PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
PE4H ver1.0 User manual(PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
PE4H ver2.0a User manual(PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
Comparison List(PDF):   Taiwan   Taiwan 2 Mirror   China Mirror
PCIEMM-xxx Cable Comparison   Taiwan   Taiwan 2 Mirror   China Mirror
