  N265A
M.2 A Key Slot to M.2 B+M Key Gold Finger


First Impression


N265A is bypass adapter from M.2 A Key or A+E Key Slot to M.2 B+M Key Gold Finger.

You can insert the M.2 A or E Key (PCIe x1、 USB2.0) Device such as WiFi module.







Brief Taiwan 1 Taiwan 2
Schematic Taiwan 1 Taiwan 2
Buy It Now

  Features


◆ M.2 B+M Key Gold Finger
◆ Pitch 2.0mm Wafer Connector
◆ 4Pin Header Jumper Set-up for USB2.0
◆ Support Host Form factor 2242/2260/2280
◆ Support M.2 A or E Key Device
◆ Support Device Form factor 2230
◆ Support External USB2.0 function
◆ High quality connectors for long service life



      Specification


    ◆ Model Name: N265A
    ◆ Host: M.2 B+M Key Gold Finger
    ◆ Device: M.2 A Key or A+E Key
    ◆ Operation Temperature: (Commerce Grade) 0~+85
    ◆ Dimension (Maximum): L*W=80*22
    ◆ Weight: ≒10g



Package Content


N265A
Unit price: USD 50.

N265A
(M.2 A Key Slot to M.2 B+M Key Gold Finger) x1
Y05-U02-060
(USB Dupont to 5PIN Cable) x1
Flat-Head Screw x2
