Home > Product > Wireless Network Card > RTL8852BE
  RTL8852BE Combo Module
Dual Band, 2x2 Wi-Fi 6, WPA3, MU-MIMO, HE80, Bluetooth 5.0

Realtek RTL8852BE Combo Module

Product Name RTL8852BE Combo Module
Model Name


Version M.2: Wi-Fi (PCIe), Bluetooth (USB)
Product Picture
USD 15.
Related Items
相 關 配 件
MHF4-RPSMA cable 8cm
US$ 3.
MHF4-SMA cable 8cm
US$ 3.



Model Realtek RTL8852BE Combo Module
Wireless class AX1800
NGFF 2.0 / USB 2.0
Connector M.2 (Key A / E)
Form factor 2230
Antenna Connection MHF4
MIMO status 2x2:2
Wireless Standards IEEE 802.11a/b/g/n/ac/ax
802.11ax up to 574/1148 Mbps
802.11ac up to 867 Mbps
802.11n up to 300/300 Mbps
802.11g up to 54 Mbps
802.11b up to 11 Mbps
802.11a up to 54 Mbps
Operating Frequency 2.4 or 5 GHz
Flags Wi-Fi 6, WPA3, MU-MIMO, HE80, Bluetooth 5.0
Operating Temperature -20°C to +70 °C
Relative Humidity 5-90% (non-condensing)
Storage Temperature -40°C to +80°C (non-operating)
Storage Relevant Humidity 5-95% (non-condensing)
