SM Extender Board 1.0 ( Smart Media Card & xD-picture Card Extender )


Introduction:

The SM Extender 1.0 is a debug and signal detection tool for xD-picture card and Smart Media Card. It allows a xD-Picture card or a Smart Media Card to be extended from the host slot for full access to the all of signal pins.

It’s especially designed to save valuable labor and time in the production environment. The SM extender 1.0 is designed to minimize the signal degradation effects of the extender by proven design echniques. Separate Vcc and ground planes provide a low inductance path to the host’s power supply.

It has the function of over-current protection with PTC fuse. A clearly marked jumper header allows probing of all of
signal pins. It’s also a powerful tool for engineers ,or use for factory test protection.
The SM extender is constructed of high quality components for years of trouble free service.





Features



Support Card Type:

xD-Picture card & SmartMedia card (3.3V only)



Product Specifications:

Dimension :Width 45mm, Length 81.60mm, Thickness 1.6mm Min



Documents Download
Brief (PDF):   Taiwan   Taiwan 2 Mirror
Dimension (PDF):
Schematic (PDF):
